Red Radical Motorsport SR3 XXR in a studio

SR1 XXR

THE INTRODUCTION TO RADICAL

SR1 XXR STANDARD EQUIPMENT

BODY

  • Lightweight spaceframe chassis with FIA-specification safety cell and crash structure

  • LMP-inspired, high-downforce composite bodywork

  • LED race lighting including FIA high-intensity central rain lightXX-generation Le Mans pre-preg carbon composite mirrors

ENGINE

  • Gen 5 RPE liquid cooled, in-line four, DOHC, 16 Valve, 1340cc Electronic Drive-By-Wire

  • Gen 5 RPE dry sump and cooling system

  • Gen 5 RPE coil-on-plug ignition system

  • Electronic Drive-By-Wire

  • Life Racing engine management system and data logging

  • Hi-flow racing exhaust system

COCKPIT

  • Two-seater chassis with twin or single-seat options, optimised for use with a moulded race seat insert

  • AIM MXS display unit with LED rev counter, gear indicator, shift light and data logging capability

  • Dash-mounted brake bias adjuster

  • Quick release steering wheel

  • Wind deflector

DIMENSIONS

  • Length: 3860mm

  • Width: 1560mm

  • Height: 1020mm

  • Weight: 510kg

FEATURES

  • Radical four-pot calipers. 240mm dia. × 25mm, 30-vane ventilated discs front and rear

  • Aluminium, foam filled 54L fuel tank

  • Full fire extinguisher system

POWER TRAIN

  • Six-speed, integral sequential gearbox

  • Radical developed paddle-activated gearshift system with auto-blipper

  • Quaife gear final drive and limited-slip differential, reversing gear system

  • Mid-engined, rear-wheel-drive

SUSPENSION

  • Fully adjustable Nik-link suspension system, front and rear unequal length top and bottom wishbones, fabricated uprights, front and rear adjustable pushrods

  • Interchangeable roll bars

  • Intrax dampers

WHEELS AND TYRES

  • Radical cast aluminium wheels

  • 7" × 13" diameter front and 9" × 13" rears

  • Semi-slick & wet tyre options, Radical recommends Hankook

SR1 XXR OPTIONS

  • Convenience Pack (Engine oil preheater and fuel sampling/drain kit)

  • Quiet track day silencer

  • Loud exhaust LED race lights

  • Dash mounted brake bias adjuster

  • Enhanced Data Pack (SmartyCam video system with GPS and race logging, including brake pressure and steering sensors)

  • FiA certificated fuel cell

  • Nik-Link rollbar set

  • Forward-facing stay head protectors

  • Composite halo head restraint

  • Passenger seat belts and headrest

  • Driver & passenger seat inserts
